Leitech – Leitech Gewinde-Prüfdorne
Leitech thread depth gauges metric coarse thread
Thread depth gauges for metric ISO coarse threads DIN 13-6H with direct depth reading.
- Inspect thread and thread depth in one operation
- Depth reading 0.5 mm or vernier reading 0.1 mm
- Direct reading up to three times the thread diameter
- Metric ISO coarse thread DIN 13-6H
Non-binding net prices for business customers. Data are maintained automatically; only our checked quotation or order confirmation is binding.
Item numbers from technical documents and accessory lists can be copied or entered here directly for searching.
Product description
Technology and application at a glance
Open this section for the complete technical and practical details.
Show full description Close description
Thread and depth in one operation
Leitech gauges inspect the thread and record the thread depth at the same time. Hardened and ground thread inserts, a black anodised aluminium body and matt-chromed reading components support robust workshop use.
Two reading versions
Items 2750 use a 0.5 mm scale reading. Items 2751 use a finer 0.1 mm vernier and an additional clamp for the scale sleeve. Items 2752 are replaceable GO thread inserts.
Special versions and coatings
Thread inserts are also available in CrN (1800 HV), TiCN-coated (3000 HV), TiAlN-coated (3300 HV) and carbide versions.
Leitech gauges are also available for other pitches and for UNC, UNF and NPT threads to DIN ISO 228. Matching core-hole gauges and versions for American threads are available on request.
